Energy Storage & Batteries illustration pack (39 illustrations)

Energy Storage & Batteries is a Sciicons Pro illustration pack of 39 original, scientifically accurate illustrations. Energy storage and batteries for papers, posters, slides and teaching: lithium-ion charge and discharge schematics, 18650, pouch, prismatic and CR2032 coin cells, modules and packs; solid-state, lithium–sulfur, sodium-ion, redox flow, lead-acid, supercapacitors and PEM fuel cells; layered oxide, olivine and spinel cathodes, NMC particles, graphite intercalation, SEI, dendrites and electrolyte solvation; charge–discharge curves, Ragone plots, cyclic voltammetry, EIS Nyquist plots, capacity fade, glovebox assembly and battery cyclers; BMS, thermal runaway, EVs, grid storage, solar plus storage, hydrogen tanks, recycling and electrode manufacturing.

Flat, minimal illustrations on a 512 × 512 canvas with one shared palette: copper and aluminium current collectors, dark graphite, blue cathodes and yellow lithium ions. Every part sits in a named group so Recolor and Edit can target it.

Topics: energy storage, battery, batteries, lithium-ion, li-ion, 18650, pouch cell, prismatic cell, coin cell, cr2032, battery pack, solid-state battery, lithium-sulfur, sodium-ion, redox flow battery, supercapacitor, fuel cell, lead-acid, cathode, anode, nmc, lfp, lmo, graphite, sei, dendrite, electrolyte, charge discharge, ragone plot, cyclic voltammetry, eis, nyquist, capacity fade, glovebox, battery cycler, bms, thermal runaway, ev, grid storage, solar, hydrogen, recycling.

Cells & formats (7)

• Lithium-ion cell discharging · Pro
• Lithium-ion cell charging · Pro
• Cylindrical 18650 lithium-ion cell with positive cap and steel can · Pro
• Pouch lithium-ion cell with laminated aluminium foil case and two tabs · Pro
• Prismatic lithium-ion cell in a rigid aluminium can with terminals… · Pro
• Coin cell (CR2032) exploded view · Pro
• Battery cells assembled into a module and a pack with busbars · Pro

Battery chemistries (7)

• Solid-state battery · Pro
• Lithium–sulfur battery · Pro
• Sodium-ion battery · Pro
• Redox flow battery · Pro
• Supercapacitor (EDLC) · Pro
• PEM fuel cell · Pro
• Lead-acid battery · Pro

Electrode materials (7)

• Layered oxide cathode (LiCoO₂ / NMC) · Pro
• Olivine LiFePO₄ cathode · Pro
• Spinel LiMn₂O₄ cathode · Pro
• Graphite intercalation · Pro
• Solid electrolyte interphase (SEI) · Pro
• Lithium dendrite growing from the anode through the electrolyte… · Pro
• NMC cathode secondary particle made of many primary crystallites,… · Pro

Characterization (8)

• Galvanostatic charge–discharge curves · Pro
• Ragone plot · Pro
• Cyclic voltammogram · Pro
• Electrochemical impedance (EIS) Nyquist plot · Pro
• Capacity retention over cycling, fading toward the 80 % end-of-life… · Pro
• Argon glovebox for assembling coin cells with low oxygen and moisture · Pro
• Battery cycler with test channels and coin cells under… · Pro
• Electrolyte · Pro

Systems & applications (10)

• Battery management system (BMS) monitoring cell voltage, current and… · Pro
• Thermal runaway · Pro
• Electric vehicle with a skateboard battery pack under the floor · Pro
• Grid-scale battery energy storage · Pro
• Solar plus storage · Pro
• Compressed hydrogen storage tank (type IV composite cylinder) · Pro
• Battery recycling loop · Pro
• Electrode manufacturing · Pro
• Jelly roll · Pro
• Battery state of charge from empty to full · Pro

License

Included with Sciicons Pro (one-time lifetime purchase). Use the illustrations in papers, theses, posters, slides, grant figures and teaching; editable SVG with named layers. Redistribution of the files as an icon set is not allowed. See how to cite Sciicons.
